Real Street RS1600 Pistons 1600HP DLC Pins for 2JZ-GTE 146mm Long Rod 86.25mm Bore -13.77cc 8.6:1

click to zoom in

CP Pistons

Real Street RS1600 Pistons 1600HP DLC Pins for 2JZ-GTE 146mm Long Rod 86.25mm Bore -13.77cc 8.6:1

Part Number:

RS02-16KD8625LS

MSRP: $2,506.55

Your Price: $2,237.99

(You save $268.56 )

Deal ends in:

Description

Description

Real Street RS1600 Pistons 1600HP DLC Pins 2JZ-GTE 146mm Long Rod 86.25mm Bore -13.77cc 8.6:1

Additional Applications:

Supra MKIV Twin-Turbo 93-98 JZA80
Supra MKIV Non-Turbo 93-98 JZA80
SC300/Soarer 92-00 Z30
IS300 01-05 XE10
GS300/Aristo 91-97 S140
GS300/Aristo 98-05 S160

Applicable Engines:

2JZ-GE, 2JZ-GE VVTi, 2JZ-GTE, 2JZ-GTE VVTi

Bore:

86.25mm

Primary Application:

Toyota Supra MKIV

Rod Length:

5.748" / 146mm

Rod Length Oversize:

0.158" / 4mm

Bore Oversize:

0.010" / 0.25mm

Stroke:

86mm (Standard Stroke)

Compression Ratio:

8.6:1

Pin Size:

0.866" / 22mm

Included Ring Set:

CPT-3396PVD

Included Pin:

I866-2500-25CP3C

Head cc:

45 cc

Dome cc:

-13.77 cc

Compression Height:

1.176" / 29.87mm

Piston Coating:

Skirt Coating

Skirt Type:

Full Round

Piston Material:

2618

Wrist Pin Wall Thickness:

0.250"

Wrist Pin Dimensions:

.866" x 2.500" x.250"

Pin Material:

300M DLC

Notes:

The Compression Ratio is 8.809:1

Gasket Thickness:

0.051" / 1.3mm
